ROSE Bikes One-Piece Endurance Cockpit| Handlebar/stem Combinations

Aerodynamic, lightweight and comfortable: The one-piece cockpit from our REVEAL models will now also cause a sensation on your bike. The one-piece carbon design not only creates a clean look as if from a single mould, but also has a lot to offer in terms of performance.

The basic alignment of the cockpit is clearly sporty, but offers more comfort for long rides compared to our Race Cockpit. The wider drops allow a more relaxed hand position and more control when road conditions require it. In addition, the aerodynamic angle of the stem is balanced out by the slightly rising bar top to put you in a more upright riding position.
The flattened shape in the upper area of the cockpit improves aerodynamics and offers better pressure distribution for the hands thanks to the wide contact surface. The one-piece carbon construction not only saves weight, but also absorbs vibrations and shocks caused by poor road conditions.

To ensure that shift cables and brake hoses do not interfere with the look or aerodynamics, they can be routed easily and neatly via recesses on the underside of the cockpit. This has the additional advantage that the cables remain easily accessible and the handlebar can be removed without disconnecting the cables. A bike computer can also be fitted: The matching Garmin/Wahoo mount can be integrated form-fit and is available separately as an accessory.

Details:
Carbon road bike cockpit with long distance geometry
Combined handlebar/stem unit
Lightweight and stiff, with dampening material properties
Flared drops for more comfort and control in the lower bar
Flattened bar top – aerodynamic and comfortable
Optimised flow behaviour due to negative stem angle
Hidden cable routing via recesses/cover underneath the handlebar
Completely removable without cable separation despite full integration
Approved for electronic and mechanical cable routing
Concealed interface for optional ROSE computer/light/camera mount (see below)

Technical details:
Intended use: Road bike (Endurance/Marathon)
Material: Carbon
For threadless 1 1/8” steerer tubes (28.6 mm)
Clamping height on steerer: 36 mm
Stem angle: -5°
Rise: 12 mm
Drop: 120 mm
Reach: 73 mm
Flare: 8°
Permitted weight: 120 kg (system weight of cyclist, bike and luggage)
Weight: approx. 375 g (measured for 420 mm x 110 mm, incl. cover, bolts and Ahead cap)

Note:
The design and cable routing are matched to current road/gravel bikes from ROSE. For third-party brands or older models, please check compatibility in advance or contact the manufacturer if in doubt.

Available in handlebar width/stem length:
90 mm / 40 cm
100 mm / 42 cm
110 mm / 42 cm
120 mm / 42 cm
Please indicate your choice.

In the box:
1 ROSE one-piece Endurance cockpit incl. cover for cable routing
Ahead cap 1⅛“
1 cover for computer mount

Note:
It is not possible to fit an aerobar.

Tip:
The matching Garmin/Wahoo mount stem bracket for mounting a bike computer can be found under prod. code: 2322009.
Note:
No warranty for damage caused by non-approved mounts.
